Auto Batch Expander Machine For Concrete Brick

This auto Batch expander Machine applies PLC and touch screen, automatic feeding, electronic weighting, temperature control, material level control to realize automatic production and assure the density of the foamed material. Automatic working process to save labor and more precise density control.

Product description:

Auto Batch expander machine applies PLC and touch screen, automatic feeding, electronic weighting, temperature control,

-Auto batch expander machine for concrete brick equipped with stainless steel fluidized drying bed which can dry, crush and filter the expanded material automatically.

image001(001)

Auto batch expander machine for concrete brick make use of an innovative expansion chamber designed to ensure the uniform distribution of steam. The fluidized bed is designed to guarantee uniform diffusion of the air inside it, in order to dry the material quickly and speed up the discharging phase.

Technical date for auto Batch Expander Machine:

Item		Unit			Type/Technical Data
			PSJ600		PSJ1100	PSJ1500I-II	PSJ1600I-II
Expansion Chamber	Diameter	mm	600		1100	1500	1600
	Usable Volume	m³	0.2		1	3.1	3.5
Steam	Entry Diameter	/	DN50		DN50	DN65	DN65
	Consumption	kg/cycle	4/6		6/8	10/12	11/14
	Pressure	Mpa	0.4-0.8		0.4-0.8	0.4-0.8	0.4-0.8
Compressed Air	Entry Diameter	/	DN25		DN25	DN25	DN25
	Consumption	m3/cycle	0.5-0.8		0.9-1.1	0.6-0.9	0.7-1.0
	Pressure	Mpa	0.5-0.8		0.5-0.8	0.5-0.8	0.5-0.8
Drainage	Upper Drainage Diameter	/	DN100		DN100	DN150	DN150
	Lower Drainage Diameter	/	DN65		DN100	DN100	DN100
Material conveying line		mm	￠150*2		￠150*2	￠150*2	￠150*2
Electronic weighing		Kg	0-50		0-50	0-150	0-150
Connected load		Kw	16.05		18.5	19.5	19.5
Type of Material Conveyor		/	Screw Conveyor/Vaccum Conveyor
Proportional Valve		/	Request
Type of Drying		/	Fluidized Drying Bed
Expanded Density	First expansion	g/l	30-80	11-40		11-40		11-40
	Second expansion		/	/		4.5-8		4.5-8
Density Tolerance		/	＜±2.5%	＜±2.5%		＜±2.5%		＜±2.5%
Capacity		g/l-kg/h	30-235	11-350		4.5g/l-350kg/h		4.5g/l-350kg/h
			40-310	15-550		7g/l-450kg/h		7g/l-450kg/h
			50-390	20-750		9g/l-550kg/h		9g/l-550kg/h
			70-540	30-850		/		/
Overall Dimension(LxWxH)		mm	5800×1130×3600	5900×2900×4500		9000×3500×5500		9000×3500×5500

Below is a display of the batch pre expander working process for eps shape moulding:

details of eps pre expander line

Cooperation cases for eps pre expander and shape moulding machine:

Cooperation Cases for EPS Project (1)_

Cooperation Cases for EPS Project (4)_

Cooperation Cases for EPS Project (2)_

eps pre expander supplier

How does the batch expander machine look like before delivery?
